In Situ TEM Solutions

In situ TEM video of perovskite solar cell
Perovskite solar cell gif

Thermal degradation of a perovskite solar cell

DENSsolutions in situ TEM sample holders

An in situ TEM system greatly increases the capabilities and experimental possibilities of a TEM. Using special holders, a sample can be heated or biased within the TEM’s vacuum chamber. More recently, liquid- or gas-phase experiments have become possible using vacuum-compatible MEMS chambers with electron-transparent windows.

DENSsolutions was founded by a group of scientists who wanted better control over their in situ TEM experiments than what could be achieved with the available products. Together, they designed holders and MEMS nano-chips that provide more flexibility, better control, and minimal drift.

Nanoscience Instruments is the sole distributor for DENSsolutions products in the US. Our dedicated sales, applications, and service staff have over a century of combined EM experience.


Our In Situ Products

Liquid

The DENS Solutions Stream in situ liquid environment TEM sample holder
Stream allows liquid phase experiments with precise control over both flow rate (0-200 nL/min) and pressure (0-2000 mbar).

Heating

The DENS Solutions Wildfire in situ heating TEM sample holder
Wildfire heats samples up to 1300°C while maintaining an incredible temperature stability of only 0.005°C.

Biasing & Heating

The DENS Solutions Stream in situ heating and biasing TEM sample holder
Lightning adds biasing up to 100V, and electric fields up to 300 kV/cm, to the Wildfire’s heating performance.

Gas

The DENS Solutions Stream in situ atmosphere TEM sample holder
Climate controls the gas environment up to atmospheric pressure, and can continuously mix up to three gasses.


Advantages of In Situ Holders


Experimental capabilities in an in situ TEM

Enable more experiments by enabling a wide range of conditions for in situ studies.


In situ gas environment sample holder

Protect the TEM with redundant isolation between the nanochip’s environment and the TEM column.


FEI Themis TEM

Compatible with any JEOL or FEI/ThermoFisher TEM, including restrictive pole piece gaps.



Multi-physics temperature modeling of in situ MEMS chip

Advanced MEMS design process, multiphysics modeling, and experimental verification to ensure consistent performance.


Vastly lower drift than other in situ solutions. No need to rely on unreliable drift correction software, even for overnight acquisitions.


High temperature EDS measurements with in situ TEM

EDS measurements during in situ experiments. The nano-chips provide high EDS counts even for low take-off angle detectors.


What Is In Situ TEM?

The limitations of conventional TEM

Conventional TEM’s primarily act as an imaging tool to characterize structures of materials.

In the last few years, state-of-the-art TEMs have enabled atomic resolution imaging and analysis, which has been achieved through the use of image or probe aberration-corrected TEMs. The performance of these TEMs as an imaging tool has proven to be extremely valuable in identifying various material structures.

However, these conventional TEMs are still unable to support the whole research process. The reason is that conventional TEM is unable to replicate real-world environmental conditions (heating, gas, liquid, etc.) as the sample is always introduced into a static, high vacuum environment.

This fundamentally limits the value and obtainable benefits of a TEM.

The power of in situ TEM

Observing processes “on site” as they are occurring and under changing external stimuli is the paramount goal of in situ, time resolved techniques.

DENSsolutions utilizes MEMS devices, called Nano-Chips, to control the sample’s environmental surroundings and replicate real-life application conditions inside your TEM. The introduction of in situ capabilities into a TEM transforms the system from a static imaging tool into a multi-functional laboratory.

With these in situ microscopy solutions, researchers are now able to characterize structures, measure properties, evaluate performance, and optimize processes & synthesis – all in one system!

If you are interested in learning more about the possibilities of in situ TEM, please contact our applications experts using the form below.


Contact Us To Learn More



    The Stream provides precise control of both pressure and flow rate,
    allowing beam-induced bubbles to be precisely manipulated or dissolved altogether.
