Quartz Crystal Microbalance with Dissipation (QCM-D)

QSense QCM-D technology and instrumentation enable analysis of molecular interactions and surface properties

Contact

Compare QSense Instruments

QSense Model

Pro

Analyzer

Explorer

Initiator

Product Image of the QSense Pro Product Image of the QSense Analyzer Product Image of the QSense Explorer Product Image of the QSense Initiator
Sensors and sample handling system
Number of sensors 8 (4 parallel in flow) 4 1 1
Volume above each sensor ~ 15 μl ~ 40 μl ~ 40 μl ~ 40 μl
Minimum sample volume ~ 50 μl ~ 200 μl ~ 200 μl ~ 200 μl
Working temperature ± 0.02 *A 4-70 °C 15-65 °C 15-65 °C 20-45 °C
Minimum dispense volume 1μl*
Sensors Gold, SiO2, Ti and other metals, oxides, nitrides, steels, glasses, polymers, etc.
Measurement Characteristics
Time resolution < 100 data points per second < 100 data points per second < 100 data points per second 2 data points per second
Maximum mass sensitivity in liquid ~ 0.5 ng/cm2 C ~ 0.5 ng/cm2 C ~ 0.5 ng/cm2 C
Normal mass sensitivity in liquid ~ 1.8 ng/cm2 F ~ 1.8 ng/cm2 F ~ 1.8 ng/cm2 E ~ 1.8 ng/cm2
Maximum dissipation sensitivity in liquid ~ 0.04 x 10-6 C ~ 0.04 x 10-6 C ~ 0.04 x 10-6 C
Normal dissipation sensitivity in liquid ~0.1 x 10-6 F ~0.1 x 10-6 F ~0.1 x 10-6 E ~0.1 x 10-4
Software
Analysis software QSense Dfind QSense Dfind QSense Dfind
Output parameters Frequency, dissipation, modeled values of mass, thickness, and viscoelasticity. Frequency, dissipation, Sauerbrey mass
Import/export Excel, BMP, JPG, WMF, GIF, PCX, PNG, TXT
Hardware
Electronics unit (HxWxL in cm) 70x67x57 18x36x21 18x36x21 18x36x21
Chamber (HxWxL in cm) 70x67x57 12x23x34 5x10x15 5x10x15
Learn more QSense Pro QSense Analyzer QSense Explorer QSense Initiator
  • A The temperature stability depends on variations in how the ambient temperature affects the warming or cooling of the chamber.
  • B Smallest sample volume to pick up and dispense. Note that the smallest volume needed for measurement is 50 µl.
  • C Data from one sensor in single frequency mode. One data point collected every 5 seconds. The Sauerbrey relation is assumed to be valid.
  • E Data from multiple frequency modes (all harmonics). Four data points are collected within 1 second. The Sauerbrey relation is assumed to be valid.
  • F Data from all sensors in multiple frequency modes (all harmonics) are collected within 1 second. The Sauerbrey relation is assumed to be valid

All specifications are subject to change without notice.
