Resin Mount & Metallurgical Stage Inserts

Resin mounted and surface polished samples are useful when investigating grain structures, revealing cross-sections, or performing failure analysis. Resin Mount Stage Inserts for the Phenom XL clamp the sample near the top surface, so all samples will remain level and at the same working distance without modifying their bottom surfaces, ideal for automated imaging and/or quantitative EDS analysis.



Sub Size Flexibility

Available in three standard sizes: 25mm (1 inch), 32mm (1 ¼ inch), and 40mm (1 ½ inch) diameters

Easy Sample Loading

Quickly load samples with an easy clamping mechanism with allen key.

Consistent Imaging

Maintains all samples at the same working distance, allowing you to maintain the same imaging settings.
